1200×300 LED Panel Light 40W 4000 Lumen 100-277v Neutral White 4000K TUV Certification

1). Item No: OX-PA30120-40W
2). Wattage: 40W (36w available)
3). Size: 1×4 ft (295*1195mm)
4). CRI>80, RA90 is Optional.
5). Luminous  efficiency: 80-100lm/W.
6). Cool White, 5500K.Nature White,4500k,Warm White 3000k

Inquiry Now

Product Description

  • 1200×300 LED Panel Light 40W

    Edge-Lit LED Panel lights 1×4 is bright and powerful ,the 40 watts led panel light has 216 leds with an output of 4000 lumens .Natural white leds have a 4500k color temperature and emite a wide 120° beam angle.



    These lights are Environmentally friendly – fully recyclable,simple and covenient installation.TUV Led panel light kits are from the top quality compoments, including EPISTAR 2835 SMD from Taiwan,Mitisubishi lighting guide diffursers from japan and grade aluminium 6063 for good heat.



    Features

    • 5 Year  Warranty
    • Watts 36w or 40w
    • Top Lumen 110lm/w
    • CE RoHS and TUV Certification
    • Ceiling LED luminaires with aluminum frame in high value design
    • Energy Savings of up to 50%
    • Lumen Maintenance over 70% @ 50,000+ Hours
    • For ceiling mounting or pendant mounting
    • The driver PFC can be up to 0.95.
    • No UV/IR Radiation / No RF Interference
    • Best famous brand drivers are used: Meanwell or Tridonic .
    • Installation: Suspension/Wall Mount, Recessed/Ceiling Mount
    • 8+ Years OX LIGHTING Design & Manufacturing

    Applications

    • Office Lighting
    • Production Area
    • Warehouse Lighting
    • Restaurants
    • Meeting Rooms
    • Transportation
    • Undercabinet Lighting
    • Hallway & lobbies

    Available Options

    • Other size   295X1195mm  595X1195mm  195x595mm  400x400mm
    • Other voltage 175-265v,  100-277v, 0-10v
    • Other colorSilver,White Paint
    • Other C.C.T. 3000k, 4000k,5500k, 6500k
Item No

OX-PA30120-40W

Power

40W

Voltage

85-265V

Frequency (hz)

50/60 HZ

Power Factor

>0.9

CRI

80

Beam Angle (Degree)

120 beam angle

Chip Brand

Epistar

LED Quantity

216 pcs

Luminous (LM)

>4000LM

Luminous Flux

100LM/W

Dimmable

NO

Material

Aluminum

Protection Rating

IP20

Certification

CE RoHS TUV

Warranty

5 Years

Applications

Office Lighting Restaurants Hotels Schools Hospitals Meeting Rooms

Reviews

There are no reviews yet.

Be the first to review “1200×300 LED Panel Light 40W 4000 Lumen 100-277v Neutral White 4000K TUV Certification”

Model Watts Qty/Ctns GW/KG
OX-PA3030-18W 18W 4 5.36 0.005
OX-PA6060-36W 36W 4 20.5 0.102
OX-PA3060-40W 40W 4 20.5 0.108
OX-PA60120-60W 60W 2 22.5 0.096
