300×300 LED Panel Lights 18W 1800 Lumens Cool White Ra>80 CE RoHS 5 Years Warranty

1). Item No: OX-PA3030-18W
2). Wattage: 18W
3). Size: 1×1 ft (295*295mm)
4). CRI>80, RA90 is Optional.
5). Luminous  efficiency: 100-120lm/W.
6). Cool White, 5500K.Nature White,4500k,Warm White 3000k

Inquiry Now

Product Description

300×300 Led Panel Light 18W

Choose best quality LED panel lights and office lighting to decorate your office with 300mm led panel light 18 watts.
It’s very convenient to install ,These edge-lit panel lights are energey-saving ,fully recyclable.we can replace the traditional fluorescent tube fixture light.



18w  led panel 300×300 are the top quality compoments, including EPISTAR 2835 SMD from Taiwan,Mitisubishi lighting guide diffursers from japan and grade aluminium 6063 with white finish and is designed for 30,000 hours of use—3 times longer than fluorescent panels.



Not only led panel lights 18w are a high lumen light source,they also use a high efficiency current driver system.18W panel lights is with an output 1800lm and power factor up to 0.95.



Features of  LED Panel Light 18w

♦ Long Life: Outstanding operational life time expectation of up to 50,000 hours
♦ Zero UV Emissions: LED illumination produces little infrared light and no UV emissions.
♦ Energy Efficiency: Todays most efficient lighting. Energy saving of estimated 80%-90%.
♦ Design Flexibility: LEDs can be combined in any shape to produce highly efficient illumination,up to 130lm/w
♦ Easy Installation: Suspension/Wall Mount, Recessed/Ceiling Mount
♦ Low-Voltage: A low-voltage power supply is sufficient for LED illumination.
♦ Instant Lighting: LED lights brighten up immediately and when powered on.
♦ Aluminum heat sink to extend life of LED product   ♦ 8+ Years OX LIGHTING Design & Manufacturing

LED Applications

♦ Window displays for retail stores, office lighting, sales outlets and shopping arcades
♦ High-performance lighting solutions for exhibitions, conferences and production area
♦ Energy saving replacement for lighting of commercial buildings, businesses, hotels etc.

 Available Options
♦ Other size available : 295X1195mm  595X1195mm  195x595mm  400x400mm
♦ Other Color available:WW(warm white) NW(Natural white) CW(Cool White) R.G.B(Red/Green/Blue)
♦ Other Voltages available:175-265v,100-277v



Item No

OX-PA3030-18W

Power

18W

Voltage

85-265V

Power Factor

>0.9

Luminous (LM)

1800LM

Beam Angle (Degree)

120 Degree

CRI

80

Chip Brand

Epistar

LED Quantity

108pcs 2835 leds

Rated lifetime (h)

50 000hrs

Certification

CE RoHS TUV

Warranty

5 Years

Applications

Exhibition Hall, art galleries, museums Hallway & lobbies Meeting Rooms

Reviews

There are no reviews yet.

Be the first to review “300×300 LED Panel Lights 18W 1800 Lumens Cool White Ra>80 CE RoHS 5 Years Warranty”


Model Watts Qty/Ctns GW/KG
OX-PA3030-18W 18W 4 5.36 0.005
OX-PA6060-36W 36W 4 20.5 0.102
OX-PA3060-40W 40W 4 20.5 0.108
OX-PA60120-60W 60W 2 22.5 0.096
