Home >> Products >> Dust Proof Light Fixtures 20W 2400 Lumens 6500K Cool White CE RoHS TUV Certification

Dust Proof Light Fixtures 20W 2400 Lumens 6500K Cool White CE RoHS TUV Certification

1). Item No: OX-TR60-20W
2). Wattage: 20W
3). Size: 600MM
4). CRI>80, RA90 is Optional.
5). Luminous  efficiency: 120lm/W.
6). Cool White, 5500K.Nature White,4500k,Warm White 3000k

Inquiry Now

Product Description

Dust Proof Light Fixtures 20w

LED Tri-proof Lights 20W means corrosion-proof,water-proof and dust-proof.it comes with 2400 lumens,every watts up to 120 lumens.it uses excellent heat dissipation of 6063 aluminum alloy houring.

The cover and outer housing are sealed with high elasticity rubber band and water proof silicone of IP66.The LED Chips is from EPISTAR of the 120 PCS 2835 smds.For the led driver,which is isolated and passed TUV UL CE RoHS ,the power factor is up to 0.95.



600MM 20W LED tri-proof lights is perfect replacement for t8 fluorescent lights and CFLS,these lights have long lifespan over 50 000 hrs.

There are three ways of installation which are surface mounted ,suspendant and linkable.And these tri-proof lights can be used widely for Parking Garage, Warehouse Facility,workshops, warehouses.

There are different color avaliable,include warm white 3000k, natural white 4500k and cool white 6500k.The guarantee is 5 years .

Features

  • 5 Year  Warranty
  • Watts 20W
  • Top Lumen 100-120 lm/w
  • CE RoHS and TUV Certification
  • Ceiling LED luminaires with aluminum frame in high value design
  • Energy Savings of up to 50%
  • Lumen Maintenance over 70% @ 50,000+ Hours
  • For ceiling mounting or pendant mounting
  • The driver PFC can be up to 0.95.
  • No UV/IR Radiation / No RF Interference
  • Best famous brand drivers are used: Meanwell or Lifud .
  • 8+ Years OX LIGHTING Design & Manufacturing

Applications

  • Office Lighting
  • Production Area
  • Warehouse Lighting
  • Restaurants
  • Retail Store Display Lighting
  • Transportation
  • Undercabinet Lighting
  • Hallway & lobbies

Available Options

  • Other power 3W/6W/12W/15W/18W/24W
  • Other voltage 175-265v,  100-277v, 0-10v
  • Other colorSilver,White Paint
  • Other C.C.T. 3000k, 4000k,5500k, 6500k



Item No

OX-TR60-20W

Power

20W

Power Factor

0.95

Voltage

85-265V

Frequency (hz)

50/60HZ

CRI

80

Luminous Flux

120LM/W

Luminous (LM)

>2400 Lumen

Chip Brand

Epistar

LED Chip

2835 SMD

LED Quantity

120 PCS

Beam Angle (Degree)

180 Degree

Color Temperature(CCT)

3000k 4500k 5500k,6500k

Certification

CE RoHS TUV

Dimmable

Yes

Material

Aluminum +PC cover

Size

600mm

Rated lifetime (h)

50 000 HRS

Warranty

5 years guarantee

Applications

industrial lighting, warehouses, parking garages, tunnels

Reviews

There are no reviews yet.

Be the first to review “Dust Proof Light Fixtures 20W 2400 Lumens 6500K Cool White CE RoHS TUV Certification”

Model Watts Qty/Ctns GW/KG
OX-TR60-20W 20W 6 10.5 0.067
OX-TR90-30W 30W 6 15.8 0.089
OX-TR120-40W 40W 6 17.6 0.111
OX-TR150-50W 50W 6 20.8 0.137
OX-TR180-80W 80W 6 31.5 0.168
OX-TR240-100W 100W 6 35.3 0.22

   DOWNLOAD

   (categlogue,IES ,Test Report)
