LED Tri-proof Luminaires 80W 9600 Lumens Cool White 6000-6500k with CE RoHS TUV Certification

1). Item No: OX-TR180-80W
2). Wattage: 80W
3). Size: 1800MM
4). CRI>80, RA90 is Optional.
5). Luminous  efficiency: 120lm/W.
6). Cool White, 5500K.Nature White,4500k,Warm White 3000k

Inquiry Now

Product Description

9600 Lumens LED Tri-proof Luminaires 80W

LED Tri-proof luminaires 80w comes with high output 9600 lumens,432pcs smd 2835 chip giving out 120 lumens per watt.6ft led tri proof luminaires comes with different installation,such as wall bracket ,suspension kit and linkable options.No mater which way to install,it is very easy and convienient.



80w led tri-proof luminaires produced with high quality,6063 aluminuam alloy for heat dissipation,high transmittance PC cover and passed TUV Ul led driver.This luminaires offer 5 years guarantee warranty.it has liftspan 50 000hrs,which means to use more than 27 years ,if it last to light 8 hours for every days.



180cm longth of tri proof led luminaires use widely,the application of factory,warehouse, supermarket, shopping malls.Because of energy saving 50% and stable and durable,it is very ideal replacement for fluorescent tube or CFLs.80w led tri proof also has different color ,cool white 6000-6500k, netrual white 4500-5000k
and warm white 2700-3000k.

Features

  • 5 Year  Warranty
  • Watts 80W
  • Top Lumen 100-120 lm/w
  • CE RoHS and TUV Certification
  • Ceiling LED luminaires with aluminum frame in high value design
  • Energy Savings of up to 50%
  • Lumen Maintenance over 70% @ 50,000+ Hours
  • For ceiling mounting or pendant mounting
  • The driver PFC can be up to 0.95.
  • No UV/IR Radiation / No RF Interference
  • Best famous brand drivers are used: Meanwell or Lifud .
  • 8+ Years OX LIGHTING Design & Manufacturing

Applications

  • Office Lighting
  • Production Area
  • Warehouse Lighting
  • Restaurants
  • Retail Store Display Lighting
  • Transportation
  • Undercabinet Lighting
  • Hallway & lobbies

Available Options

  • Other power 20W/30W/40W/50W/60W/80W/100W
  • Other voltage 175-265v,  100-277v, 0-10v
  • Other colorSilver,White Paint
  • Other C.C.T. 3000k, 4000k,5500k, 6500k



Item No

OX-TR180-80W

Power

80W

Power Factor

0.95

Voltage

85-265V

Frequency (hz)

50/60HZ

CRI

80

Luminous Flux

120LM/W

Luminous (LM)

>9600 Lumen

Chip Brand

Epistar

LED Chip

2835 SMD

LED Quantity

432 PCS

Beam Angle (Degree)

180 Degree

Color Temperature(CCT)

3000k 4500k 5500k,6500k

Certification

CE RoHS TUV

Dimmable

Yes

Material

Aluminum +PC cover

Size

1800mm

Rated lifetime (h)

50 000 HRS

Warranty

5 years guarantee

Applications

industrial lighting, warehouses, parking garages, tunnels

Reviews

There are no reviews yet.

Be the first to review “LED Tri-proof Luminaires 80W 9600 Lumens Cool White 6000-6500k with CE RoHS TUV Certification”

Model Watts Qty/Ctns GW/KG
OX-TR60-20W 20W 6 10.5 0.067
OX-TR90-30W 30W 6 15.8 0.089
OX-TR120-40W 40W 6 17.6 0.111
OX-TR150-50W 50W 6 20.8 0.137
OX-TR180-80W 80W 6 31.5 0.168
OX-TR240-100W 100W 6 35.3 0.22
